The BBO crystal is a high-performance electro-optic modulation material. It offers a high laser damage threshold (LIDT) and transmits light from 190 nm to 3500 nm. This makes it ideal for laser systems across the UV to mid-infrared range.
Its strong damage resistance and fast response are perfect for high-repetition-rate Q-switching. This enables stable and efficient pulsed laser operation.
Our crystals are polished to laser-grade precision. The surfaces are highly accurate and smooth, which minimizes insertion loss and scattering.
Each crystal is coated with Cr-Au composite electrodes. These provide excellent conductivity and adhesion for uniform electric field distribution. This improves modulation efficiency and long-term reliability.
BBO crystals are used in advanced optoelectronic systems. Applications include electro-optic Q-switching, laser mode-locking, optical switching, and phase modulation. They are widely used in research, industrial processing, medicine, and communications.
| Size (mm3) | Orientation | Coating | Surface Quality | Order |
| 3*3*20 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
40/20 |  |
| 3*3*20 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
20/10 | |
| 3*3*25 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
40/20 | |
| 3*3*25 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
20/10 | |
| 4*4*20 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
40/20 | |
| 4*4*20 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
20/10 | |
| 4*4*25 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
40/20 | |
| 4*4*25 | z-cut | S1&S2-AR@1064nm S3&S4-Au&Cr Film |
20/10 | |
| 20*20*20 | z-cut | S1&S2-AR@1030nm S3&S4-Au&Cr Film |
40/20 | |
